2.INTRODUCTION

Specification

Model	TINA2S V12
Build Volume	100 x 105 x 100mm /3.9’’x 4.0’’x 3.9’’
Nozzle Diameter	0.4mm
Layer Thickness	0.1-0.4mm
Platform Material	Flexible Spring Steel
Leveling Tech	9-Point Auto Bed Leveling
Max Nozzle Temp	245°C
Motherboard	R72F
Max Heated Temp	60°C
Max Print Speed	80mm/s Manual adjustment up to 150 mm/s may result in significant quality degradation.
Print Precision	±0.1mm
Product Weight	3Kg/6.6lbs
Power Supply	AC 100-240V, DC 12V5A, 60W
Filament Diameter	1.75mm
Supported Filament	PLA / PLA+ / TPU
Filament Capacity	100-250g (built-in holder) 1kg (with extra rack)
Slicing Software	Wiibuilder (Win / Mac) Cura (Win / Mac) Kiri (Chrome OS / iPad） OctoPrint (Pi / Linux)
Input File Format	STL / OBJ / AMF
Print Format	G-code
Input Method	App / TF Card / Wi-Fi / USB
APP	Poloprint Cloud (Android / IOS)
